Dome Camera

Dome Camera
Dome Camera
Product Code : DR-540VF
Product Description

Dome Camera

DR – 540VFis a Color Dome Camera with 1/3” Sony Super HAD CCD image sensor. It's aesthetically appealing design and white color dome makes it best suited for any indoor application. The combination of enhanced picture quality reliability and cost – effectiveness makes this camera an excellent choice for all installers.

  • Discreet Indoor Surveillance
  • 0.1Lux Minimum Illumination
  • 3 Axix Construction
  • True Color Reproduction
  • Automatic Backlight Compensation

Specifications

Image Sensor

1/3” Sony Super HAD CCD

Effective Pixels

NTSC:500(H) x 582(V) PAL:510(H)x494(V)

Sync Mode

Internal

Horizontal Resolution

540TVL

Video Output

1.0Vp-p(75Composite)

S/N Ratio

48dB

Lens

3.6mm – 9MM Varifocal Lens

Minimum Illumination

0.1Lux/F1.2

Shutter Speed

NTSC:1/60 ~ 1/120,000sec, P AL:1/50 ~ 1/120,000 sec

White Balance

Auto

ES/BLC

Auto

AGC

Auto

Compliance

CE, FCC, RoHs

Supplied Voltage

DC12V

Dimension

128(dia)x91(H)mm

Weight

300g

Consumed Current

150mA

Operating Temperature

-10C~50C, RH95% MAX(Non Condensing)

Design & specifications are subject to change without any prior notice
